ABB  UNS0874A-P,V1 3BHB002651R0001  模塊

ABB  UNS0874A-P,V1 3BHB002651R0001  模塊

ABB  UNS0874A-P,V1 3BHB002651R0001  模塊

UN5000系列ABB勵磁備件清單

序號 備件名稱 參數 零件號

1 COB 主控制板 UNS2880B-P,V1 3BHE014967R0001

COB 主控制板 UNS2880B-P,V2 3BHE014967R0002

2 MUB 測量單元板 UNS2881b-P,V1 3BHE009319R0001

3 CIN 整流器接口板 UNS0880a-P,V1 3BHB005922R0001

4 GDI門板驅動接口板 Gate Driver Interface UNS0881a-P，V1 3BHB006338R0001

5 PSI 功率信號板 Power Signal Interface UNS0882a-P var.1 3BHB006309R0001

6 FIO 快速輸入/輸出接口板 Fast I/O UNS0883A-P,V1 3BHB006208R0001

7 CUS電流傳感器 Current Sensor UNS0884a-V1 (3BHE004385R0001)

8 CDP 整流橋顯示屏 Converter Display UNS0885A-Z,V1 3BHB006943R0001

9 ROI 繼電器輸出接口板 AR C093 AE01 HIEE300690R0001

10 電源模塊 Power supply pack 3BHB006449R0002

11 電源濾波器 Filter MFS3N-230V 3BHE003523R0030

12 過電壓保護器 Overvoltage Protection UNS4681 V.511 3BHE004074R0511

13 可控硅元件 Thyristor 4200V 3BHE013707R0003

14 整流橋風扇 Fan for UN133xx Converter GDRM35-133B-2 HIER465117P0001

15 風機單元 Ventilation Unit for UN133xx Converter 4x280VA HIER329036P0004

16 冷卻風扇 Door fan(AVR柜) SK3326.107 230V 3BHE007153R0001

17 跨接器觸發板 Crowbar Firing Board UNS0017A-P，V1 HIEE305106R0001

18 滅磁開關(HPB45) Field Breaker HPB45, 1000Vdc 3BHE010103R4421

19 滅磁開關(HPB60) Field Breaker HPB60, 2000Vdc 3BHE010103R4x21

20 滅磁開關合閘線圈 Closing Coil 1SDA038300R0001

21 滅磁開關跳閘線圈 Tripping Coil 1SDA038290R0001

22 電流變送器Transducer HIER469038P0001 (現為HIER466823P0001)

23 電壓變送器transducer MCR-C-UI-UI-DCI HUAD401152P0001

24 電壓分配器 Voltage divider WOTAGE DIVIDER DIV0 1000/100V CL.1 50HZ HIER464661P0001

25 直流接觸器 Contactor GJL1213001R7101

26 直流接觸器 Contactor 1SBL283001R8622

27 監視繼電器 Monitoring Relay HIER466586P2023

28 繼電器 HIER454760P0001

29 繼電器座 HIER446489P0001

30 繼電器 3BHB002782R9110

31 繼電器 3BHB002782R9024

32 濾網 HIER467078P0001

a.1 快熔 HIER465095P0003

a.4 熔絲 Fuse 1500Vac 50A HETT401476P0014

a.5 熔絲座 PSII20.127PRE 3BHE002966R0002

b.1 MCB開關 GHS2810164R0338

b.2 MCB開關 GHS2820164R0427

b.3 MCB開關 GHS2820164R0487

b.4 MCB開關 GHS2820164R0537

b.5 MCB開關 GHS2820001R0427

b.6 MCB開關 GHS2830001R0467
